PV2R32 Vane Pumps with High Pressure and Lower Noise
Key words:
Details
Specifications
Series | Displacement of shaft end pump | Displacement of cover end pump |
PV2R32 | 52、60、66、76、94、116、125、136 | 17、26、33、41、47、53、59、65、70、75、85 |
Model code
Installation and Usage
Note:
1.When pressure of pumps exceeds 16MPa, with displacement of“4”“6” “8”, , speeds should be more than 1450 r/min.
2. Reduce the negative pressure of the inlet when the Single Pump or double pumps with large displacement at high speed.
3. The numerical number in bracket is the one using phosphate ester fluid and water containing hydraulic fluid.
4. Speed at 1000r/min is suggested on occasions with lower noise strictly required.
5. When the working fluid is phosphate ester fluid, it uses special sealing (FPM), Prefix [F3-] to the specified model when ordering.
6. Input power is available in working conditions of 16MPa and 1500r/min.
Installation Connection Dimensions
