1. During installation, the concentricity tolerance of the pump and motor must be less than 0.10mm (TIR), and the maximum allowable angular error must be less than 0.2 degrees. When using a flexible coupling, the pump shaft must not bear radial and axial loads; the bracket must be sturdy, rigid, and able to fully absorb vibration.
2. During installation, it is recommended that the pump's suction port be conveniently located for oil suction during startup.
3. Secure the piping, especially the inlet pipe, according to the diameter size, and install a safety pressure relief valve in the system; the set pressure of the safety valve must not exceed the maximum pressure of the pump; the inlet pipe must be strictly sealed to prevent oil leakage, and the return oil nozzle should be below the liquid level.
4. Check the inlet and outlet and rotation direction before starting the pump. When operating the pump, if it is a newly installed or pump that has not been used for a long time, air must be released from the outlet.
And start the pump as much as possible under no-load conditions (preferably with the pump full of oil).
5. When the pump is mounted above the oil surface of the tank, the suction height should be less than 500mm, the inlet port should be below the oil surface of the tank, and the positive pressure of the inlet port should be limited to within 0.03 MPa.
6. The oil should be kept clean; the pipes and tank must be thoroughly cleaned. Install a filter with sufficient capacity 50mm above the pump inlet, with a recommended accuracy of 100μm. A precision filter with an accuracy of 25μm should be installed in the system. The cleanliness of the oil should be within NAS12.
7. The operating temperature of the oil should be controlled between 15℃ and 55℃. If starting the pump in a cold environment, the oil should be heated, and the pump should be turned on without load and continue to run without load.
8. Pay attention to the viscosity and quality of the oil. It is recommended to use anti-wear hydraulic oil such as No. 32 oil at low temperatures.
9. After fixing the pump, manually rotate the pump shaft smoothly and flexibly.
Installation Connection Dimensions
