50V high-performance vane pump

Key words:Hydraulic tools

E-mail:

Details

Specification



Series

Model

Displacement
mL/r

Speed
r/min

Rated
Pressure
MPa

Input Power
kW

Weight
kg

50V

YB-D 250

252

600-1800

10

65

70

YB-D315

316

83

YB-D355

350

94


Note: 1. Input power is available under the working conditions of 16MPa (50V, 10MPa) and 1500 rpm.

2. Under strict noise requirements, a speed of 1000 rpm is recommended.





Model Code







Installation and Use



1. During installation, the concentricity tolerance of the pump and motor must be less than 0.10mm (TIR), the maximum allowable angular error must be less than 0.2 degrees, and a flexible coupling must be used; the pump shaft must not bear radial and axial loads; the bracket must be strong and rigid, and able to fully absorb vibration.
2. During installation, it is recommended that the pump's suction port be conveniently positioned for oil suction during startup.
3. Secure the pipelines, especially the inlet pipe, according to the diameter size, and install a safety relief valve in the system; the set pressure of the safety valve must not exceed the maximum pressure of the pump; the inlet pipe must be strictly sealed to prevent leakage, and the oil return nozzle should be located below the liquid level.
4. Before starting the pump, check the inlet, outlet, and rotation direction. When operating the pump, if it is newly installed or has not been used for a long time, air should be released from the outlet.
And start the pump as much as possible under no-load conditions (preferably with the pump filled with oil).
5. When the pump is fixed above the oil surface of the tank, the suction height should be less than 500mm, the inlet should be located below the oil surface of the tank, and the positive pressure at the inlet should be limited to within 0.03 MPa.
6. The oil should be kept clean; the pipelines and tank must be thoroughly cleaned. Install a filter with sufficient capacity 50mm from the pump inlet, with a recommended accuracy of 100μm. A precision filter with an accuracy of 25μm should be installed in the system. The cleanliness of the oil should be within NAS12.
7. The operating temperature of the oil should be controlled between 15℃ and 55℃. If starting the pump in cold weather, the oil should be heated, and the pump should be started under no-load conditions and operated continuously under no-load conditions.
8. Pay attention to the viscosity and quality of the oil. It is recommended to use anti-wear hydraulic oil such as No. 32 oil at low temperatures.
9. After fixing the pump, manually rotate the pump shaft evenly and flexibly.
Installation Connection Dimensions



Install Connection Dimensions
