PV2R3 High-Pressure Low-Noise Vane Pump

Key words:Hydraulic tools

Category:

PV2R series high pressure low noise vane pumps

E-mail:

Tel:

Details

Specification

Model	Displacement mL/r	Maximum Pressure							Speed r/min		Input Power Kilowatt	Weight Kilogram
		Special Oil	Anti-wear Oil	Ordinary Oil	Anti-wear Water Ethylene Glycol Liquid	Water Ethylene Glycol Liquid	Water-oil Emulsion	Phosphate Ester Ester Liquid	Min.	Max.
PV2R3-52	52.9	21	17.5	14	16	7	7	14	600	1800 (1200)	23.2	32
PV2R3-60	64.3										29.4
PV2R3-66	67.2										34.2
PV2R3-76	76										37.7
PV2R3-94	94.2										41.2
PV2R3-116	115.8	16	16								50
PV2R3-125	127									1200	55
PV2R3-136	132.5										57

Model Code

Installation and Use

Note: 1. When the pump pressure exceeds 16 MPa, and the displacement is "4" "6" "8", the speed should exceed 1450 rpm.

2. Reduce the negative pressure of the inlet during high-speed operation of a single pump or a double pump with large displacement.

3. The numbers in parentheses are for use with phosphate ester liquids and water-containing hydraulic oil.

4. In situations with strict low-noise requirements, a speed of 1000 rpm is recommended.

5. When the working fluid is phosphate ester liquid, use a special seal (FPM). Add the prefix [F-] before the specified model when ordering.

6. Input power is available under working conditions of 16 MPa and 1500 rpm.

Installation Connection Dimensions
