PV2R2 High-pressure, Low-noise Vane Pump

Key words:Hydraulic tools

Category:

PV2R series high pressure low noise vane pumps

E-mail:

Tel:

Details

Specification

Model	Displacement mL/r	Maximum Pressure							Speed r/min		Input Power Kilowatt	Weight Kilogram
		Special Oil	Anti-wear Oil	Ordinary Oil	Anti-wear Water Ethylene glycol Liquid	Water Ethylene glycol Liquid	Water-oil Emulsion	Phosphate ester Ester liquid	Min.	Max.
PV2R2-17	17.7	21	17.5	14	16	7	7	14	600	1800 (1200)	7.8	16
PV2R2-26	26.6										11.7
PV2R2-33	32.8										15.5
PV2R2-41	41.7										18.9
PV2R2-47	47.9										23.2
PV2R2-53	55.7										24
PV2R2-59	58.2										24.9
PV2R2-65	63.3										29.4
PV2R2-70	70.3	16	16							1200	31.6	17
PV2R2-75	78.1										35.7
PV2R2-85	82.7										37.5

Model Code

Installation and Use

Note: 1. When the pump pressure exceeds 16 MPa, and the displacement is "4" "6" "8", the speed should exceed 1450 rpm.

2. When a single pump or double pump has a large displacement at high speed, reduce the negative pressure of the intake.

3. The numbers in parentheses are for use with phosphate ester liquid and water-containing hydraulic oil.

4. In situations with strict low noise requirements, a speed of 1000 rpm is recommended.

5. When the working fluid is phosphate ester liquid, use a special seal (FPM), and add the prefix [F-] before the specified model when ordering.

6. Input power is available under working conditions of 16 MPa and 1500 rpm.

Installation connection dimensions
